SAB Goblin 380 Flybarless Electric Helicopter Yellow/Blue Kit (SOLD OUT)

SAB Goblin 380 Flybarless Electric Helicopter Yellow/Blue Kit (SOLD OUT)
Click to enlarge
Price: $399.00 (Rp 6,783,000.00)
Availability: Out Of Stock
SKU: SG381
Average Rating: Not Rated

Description

The Goblin 380 provides incredible performance, reliability and simplicity with the unique and innovative Goblin look you are accustomed to!
Download Tips:

Download Manual:

http://www.goblin-helicopter.com/shop/imagesdesc/Untitled-11.jpg









http://www.helidirect.com/images/uploaded/Goblin_380_desc.jpg


  • Main rotor diameter: 856 mm
  • Main blade length: 380mm
  • Tail rotor diameter: 196 mm
  • Tail blade length: 70 mm
  • Main shaft diameter: 8 mm
  • Tail shaft diameter: 5 mm
  • Weight including electronics: 1075 g (excluding batteries).

Kit Includes:
  • 21T motor pulley (other motor pulleys available)
  • BL 380 3D mm main blades
  • 70 mm tail blades
  • 2 Battery tray with straps and double tape
  • Cyclic Servos: Micro size 23mm
    • General and 3D flight:  MKS   DS92A+,  Savox SH-0255MG
    • General and Extreme flight:  BK 3001HV,  SAVOX SV-1232MG,  MKS HV93,  MKS DS95
  • Tail Servo: Mini size 35 mm
    • General and 3D flight:  Savox SH-1257MG,  Futaba S9257
    • General and Extreme flight:  BK 5005HV,  MKS HV9780
  • Typical speed controller:
    • General and 3D flight: Kontronik Koby 70, YGE 60 LV, CC Lite 75
    • General and Extreme flight:  Kontronik Koby 90 - Jive 80LV ,  YGE 90 LV,  CC Lite 100
  • Maximum motor size: 41 mm diameter, 41 mm height
    • General and 3D flight: X-Nova 2820-890,  Scorpion HK 3014-900,  Quantum 2820-880
    • General and Extreme flight:
      • Kontronik Pyro 380-9,  X-Nova 3215-930,
      • Scorpion HK 3020-1000,  KDE 500XF-950.
  • Battery compartment: 44x44x130mm
    •  6S 1500/2600 mAh.  For perfect 3D flight 6S-1800 mAh
The following motor pulleys are available:
  • H0501-19-S - 19T Pinion = ratio 6.3:1
  • H0501-20-S - 20T Pinion = ratio 6:1
  • H0501-21-S - 21T Pinion = ratio 5.7:1
  • H0501-22-S - 22T Pinion = ratio 5.5:1
  • H0501-23-S - 23T Pinion = ratio 5.2:1
  • H0501-24-S - 24T Pinion = ratio 5:1

All these motor pulleys are for a 6 mm motor shaft. Each pulley includes an adapter for 5 mm motor shafts.

http://www.goblin-helicopter.com/shop/imagesdesc/keyfeas.jpg

  • Goblin Concept design.
  • Single stage transmission;
  • Heat tolerant primary drive belt;
  • Motor Belt Gates GT3 9 mm.
  • HPS (High Precision Head System);
  • 8mm high strength steel main shaft;
  • 5mm high strength steel spindle shaft;
  • New head with 2-piece blade grip preserves grips in the event of a crash.
  • Direct and geometrically correct servo placement;
  • Mini size cyclic servos.
  • Mini size tail servo.


  • Aluminum Motor mount.
  • Plenty of room for electronic components.
  • Very clean Cabling.
  • Quick release battery tray system
  • Big battery compartment;
  • wide selection of batteries with different capacities 6S 1500/2600 mAh.
  • Carbon fiber boom for very lightweight.
  • Nylon bolt break-away system to preserve the boom during a crash.
  • Dampened tail system for increased vibration tolerance;
  • Aluminum tail case for increased stiffness.
  • 5mm high strength Tail shaft
  • Carbon fiber tail push rod hidden inside the boom for an aesthetically pleasing, unique design.
  • Landing gear Goblin Speed style.
  • &am

    Additional Images

    There are no additional images for this product.
