450V3 Torque Tube Drive Assembly HS1298 (SOLD OUT)

Description

Instruction:
●Use for T-REX 450 S/GF/SE/SEV2.
●The high efficiency torque tube drive system is not only decrease the consumption of the motive power but also increase the fluency and the precision of the rudders.

Specification:
●The high efficiency torque tube drive system is not only decrease the consumption of the motive power but also increase the fluency and the precision of the rudders.
●450V3 Tail boom mount set(L) x 1
●450V3 Tail boom mount set(R) x 1
●Aluminum hexagonal bolt x 7(3x22mm)
●450V3 Tail Drive Gear Assembly x 1(Φ16.8x30.4mm)
●450V3 Front long umbrella gear x 1(Φ6xΦ10.8x17.85mm)
●450V3 Front short umbrella gear x 1(Φ2.7xΦ10.8x6.7mm)
●Bearing MR83ZZ x 4(Φ3xΦ8x3mm)
●Bearing MR106ZZ x 4(Φ6xΦ10x3mm)
●Socket button head screw x6(M2x14mm)
●Socket button head screw x8(M2x6mm)
●Washer x 1(Φ1.5xΦ5x0.3mm)
●Tail torque tube unit x 1
●Vertical stabilizer mount x 1
●Socket screw x2(M2x18mm)
●347 Tail boom x 1(Φ11xΦ12x347mm)
●Torque tube x 1(Φ3.1xΦ3.6x347mm)
Max. impact torque:12~14kg.cm
166.68~194.46oz-in
●Bearing MR84ZZ x 1(Φ4xΦ8x3mm)
●Tail boom brace x2
●Socket button head collar screw x4(M2x8mm)
●Socket button head self tapping screw x1(T2x8mm)
●M2.5 Special washer x 2(Φ2.5xΦ6x2mm)
●Tail blade x 2
